Facilities

Facilities









 Narimune Manufacturing’s Machinery and Equipment

MORI SEIKI (Vertical) MV - Junior
550 × 410 × 460
MORI SEIKI (Vertical) MV - 40
800 × 410 × 510
MORI SEIKI (Vertical) MV - 40
800 × 410 × 510  (200mm column UP)
MORI SEIKI (Vertical) MV - 45
800 × 460 × 510  (4 axis control)(200mm column UP)
MORI SEIKI (Vertical) NV-5000α1
1100 × 510 × 510  (4 axis control)(200mm column UP)
MORI SEIKI (Vertical) NVX-5100Ⅱ
1100 × 510 × 510  (5 axis control)(200mm column UP)
OHKUMA  (Vertical) 852V
2000 × 850 × 750  (4 axis control)(200mm column UP)
MORI SEIKI (Horizontal) SH-500
630 × 600 × 800  (500 square 2 palette)
DMG  DMU-80P
800 × 700 × 500  (Simultaneous 5-axis control) (Table 630)
DMG  DMU-60P duoBLOCK
600×700×600  (Simultaneous 5-axis control) (Table 630)
MAZAK NC Lathe SMART 100
φ280×310×12D



Other equipment

  Multi-axis drilling machine (2)
  Milling machine (3) (MAKINO HOWA)
  Lathe (3) (WASHINO) dill polishing machine
  Large drilling machine (2)
Ultrasonic cleaning machine (customized)















Pressure control facility

 Work size 1000 x 1000 x 1000 Maximum load 50Kg. Water temperature 40 ° MAX



Measuring Equipment List

  MITUTOYO CRYSTA APEX-EX     1200X1200X1000   REVO2
  MITUTOYO CRYSTA APEX-S       1200X1200X1000
  MITUTOYO FALCIO APEX 916     900X1200X600
  MITUTOYO CRYSTA APEX 9106  900X1000X600
  LASER PROBE
  METRIS
  M-SURF
  Shape measuring instrument Control laser-VC100
  Tokyo Precision SURFCOM 130 A (measuring length 50 mm)



Narimune Techno Engineering (Thailand)’s software facilities



  UGNX 11,12, Viewer
6 seats  (CAD/CAM)
  I-DEAS NX6
1 seat  (CAE 1 set)
  I-DEAS NX6
2 seat (CAD)
  CADDoctor EX
1 seat
  VISI CAD v.20
1 seat
  M-Surf
3 seat (3D Inspection)
  MCOSMOS v4
1 seat (CMM Online)
  DesignX
1 seat (Reverse eng.)
  Verify
1 seat (3D Inspection)
  ControlX
1 seat (3D Inspection)
  MiCAT 1.5
1 seat (CMM Offline Programming)






3D Smart Scanner
(White Light Camera)




Mitutoyo CRYSTA-Apex S 9168
(900X1600X800)



Laser Probe
SurfaceMeasure 1010
